Description
● 35SHD4001-20B
● Nema 14 Stepper Motor
● Low noise, High Torque, Low inertia
● Shaft type: Milling shaft
● Shaft length: 20mm
● Shaft diameter: 5mm
● Motor body: 26mm
● Rated voltage: 12 V
● Rated current: 0.4 A
● Holding torque: 100mN.m
Specification
| Step angle | 1.8°±5% | Phase resistance | 20ohm±10%(At 20℃) |
| Number of phase | 2 | Phase inductance | 20mH±20% |
| Rated voltage | 12 V DC | Rotor inertia | 12g.cm² |
| Rated current | 0.4 Amp | Motor weight | 0.12kg |
| Holding torque | 100mN.m | Insulation resistance | 100MΩmin.(500V DC) |
| Detent torque | 8mN.m | Insulation class | Class B |
